Mobile diagnostic services per imagine | CT Mobile

Number of detectors: 128 layers

Mobile Unit trailer- widely expandable
Dimension:
Length mt 13,50
Length mt 2,50 for transport
Expandable on both sides during operation
Height mt 4

Power supply:
Voltage 380V , 125A

Manufacturers:
GE, Philips ; Siemens

Manufacturers trailer:
SMIT, Lamboo

Number of detectors: 64 layers

Mobile Unit trailer-compact
Dimension:
Length mt 11
Length mt 2,50 for transport
Expandable on both sides during operation
Height mt 4

Power supply:
Voltage 380V , 125A

Manufacturers:
GE, Philips ; Siemens

Manufacturers trailer:
SMIT, Lamboo

TAC Mobile Units are equipped with every comfort:

  • Air conditioning system capable of ensuring the desired temperature and relative humidity conditions in every season.
  • Hydraulic stabilization plant
  • Adequate electrical installation with high quality and safety standards,
  • LAN network for data exchange and sharing with the RIS/PACS of the host hospital facility
  • Appropriate lighting for the environment according to the parameters set by regulations to safeguard the safety and well-being of both health care personnel and patients, etc.
  • Electrohydraulic platform for safely lifting stretchered or nonambulatory patients to the operating floor.
